Pitch vs. Resolution: Choosing the Right LED Density for Highway vs. Pedestrian Traffic

Demystifying Pixel Pitch

Pixel pitch refers to the center-to-center distance in millimeters between adjacent LED clusters (pixels). A smaller pitch (like P4 or P6) packs more LEDs into the cabinet for razor-sharp detail at close range, while larger pitches (P10 or P16) deliver maximum brightness and readability for long-distance highway viewing at lower hardware cost.

• P4 & P6 (High Density): Ultra-crisp detail for pedestrian plazas, drive-thrus, and slow city traffic (< 30 MPH)
• P8 & P10 (Commercial Standard): Balanced resolution and brightness for suburban commercial arterials (35–50 MPH)
• P16 (Highway Large Format): High-impact visibility for interstate freeways and high-rise pylon signs (60+ MPH)
• Viewing Distance Rule of Thumb: Minimum viewing distance (meters) ≈ Pixel pitch (mm)

Traffic Speed & Viewing Cone Calculation

Calculating driver exposure time based on road speed ensures passing motorists can comfortably read your message before driving past your frontage.

• Highway Traffic (65+ MPH): Motorists have a 4–6 second line-of-sight window; bold typography and high-contrast P10/P16 panels work best
• Arterial Roads (35–45 MPH): Allows multi-line text and dynamic product imagery on P6/P8 displays
• Pedestrian & Stop-and-Go Corridors: Crisp P4/P6 displays allow viewers to stand within 10–15 feet without seeing pixelation

Expert Density Consultations

Selecting the right pixel pitch prevents overspending on unnecessary density or underspecifying resolution. Bret Baker and our engineering team provide tailored pitch analyses based on your site's speed limit and setback.
